Drinking Bowls KN50

for low pressure

  • water bowl made from high-quality plastic
  • with low-pressure valve
  • lockable tongue (separate accessory)
  • fastening clip and stabilisation plate are not included in the scope of delivery
  • for wall and pipe mounting
Items
Ref. no.ColourWater connectionCapacityPUPallet
225035greenG 1/2" / G 3/4"2.2 L11120 PAL120 PAL
Accessories
Ref. no.DescriptionColourMaterialConnectionFrame heightPU
221971Guard Size 2 hot-dip galvanised metal 20 cm1/4
22501tube mounting bracket with stabilising plates in pairs metal  1/25
221757Adapter Plate for Pasture Barrel Attachment metal  1/5
225034Nose Paddle Plastic  1/40
223437Valve low-pressure Plastic  1/100/400
2218606Sealing plugblackPlastic3/4" 1/200


Technical dataDimensions (W x D x H)Connection optionFlow rateWeight
22503521 cm x 30,2 cm x 17 cmfrom above or below7.2 L/min at 0.5 bar, 10.8 L/min at 0.75 bar0.95 kg

Preview imageItem. No.Description225035
Low pressure valve - KN50 for223437Low pressure valve - KN50 forx
 2218606Sealing Plugs plastic 3/4''x
