Hay Cutter TF 2000 M

  • suitable for vertical as well as horizontal cutting of hay bales, allows for dust free working
  • its perfect cutting, handling and ease of use without maintenance requirements reduce labour costs
  • the TF 2000 M hay cutter is perfect for cutting hay bales, pressed fodder and silage (e.g. hay, corn, millet, beet leaves or grass silage in a clamp silo)
  • with closed blade
  • cuts round hay bales without raker
  • Sound pressure level: 103.5 LWA
  • Vibration level ISO 5349: 5.9 m/sec2
Items
Ref. no.ColourPlug typePU
29190black / blueSafety Plug E + F1


Technical dataVoltageMains frequencyPowerPlug typeWeightCutting widthCutting heightSound pressure level
29190230 V AC50 Hz1400 WSafety Plug E + F13.4 kg25 cm60 cm89.9 LpAm

Preview imageItem. No.Description29190
 HC001housing protection (knives)x
 HC001-1Housing Protec. w. Filter forx
 HC003screw M5 x 14 forx
 HC004nut M5 for screw HC003x
 HC007screw for knife for 29190x
 HC008screw nutx
 HC009fixing screw for bladex
 HC010screw for bladex
 HC011-1blades for hay cutter 29190x
 HC012Allen Screw M6x6 (No. 12)x
 HC013Washer No. 13x
 HC014protection edge forx
 HC015Bearing Shell for Anchorx
 HC017-1knives compl. closedx
 HC018Axle Boltx
 HC019Bearing Shell for Bladex
 HC020Washer No. 20 (Rondella)x
 HC021x
 HC022Bearing SKF6002/2RS (No.22)x
 HC023-1Locking Ring (No. 23)x
 HC025-ABlade Holder for 29190/29187x
 HC026Screw 8x45 for 29190x
 HC027eccentric for 29190/29187x
 HC028Bearing SKF 6006/2PS forx
 HC029Sawing Ring 55mm f 29190/29187x
 HC031Distance-ring nr. 031x
 HC032Screw for Haycutterx
 HC033x
 HC034Wedge (No. 34) 5x5x45x
 HC035Drive Shaft for Bladex
 HC036x
 HC037-AWasher (Intermediate Pce.)x
 HC039x
 HC040x
 HC042handle / cover (No. 42)x
 HC043safety leverx
 HC044spring for safety leverx
 HC045-Aon/off switch for hay cutterx
 HC046x
 HC047Handle Upper (Housing) forx
 HC048x
 HC051x
 HC052cable guide for Hay-Cutterx
 HC056grip for hay-cutterx
 HC057gear housingx
 HC060Nut for Motor Housing ofx
 HC062x
 HC063x
 HC064x
 HC065x
 HC067Fanx
 HC068x
 HC069x
 HC070Cover for Fanx
 HC071Screw for Protective Coverx
 HC072motor protection forx
 HC075Motor Housingx
 HC076-1Pole Stacked Core Wound 230 Vx
 HC081Piston Guide for 29190x
 HC084carbon for 29190, 22187x
 HC100screw kit for knivesx
 HC102bolt for knife for 29190x
 HC103knife holding device open compx
 HC104washerx
 HC105nutx
 HC110-01Anchor Complete 230 V forx
 HC111Spacer (Image No. 111)x
 HC112x
 HC117x
 HC119-01stator complete forx
 HC130Handle for Haycutter Completex
 HC041x
 HC049x
 HC050x
