Mobil Power A 1200

  • Universal, very effective 12 volt battery unit for mobile use
  • two separate LEDs for fence voltage and battery control
  • manual turn switch (1 – 10) adjusts output energy steplessly – this makes power input adjustable to adapt more efficiently to fencing conditions
  • Can be operated via a 230-V power pack (371012 - not included)
  • allows for alternative operation with 9 Volt dry battery
  • 5-year warranty

recommended solar module: item no. 375156 (15 watts)

Items
Ref. no.PUPallet
3721211133 PAL33 PAL


  • low energy consumption thanks to energy-saving mode
  • with visual fence voltage control
  • with On/Off switch, high/low
  • weather-resistant and sturdy housing
  • Can be operated via a 230-V power pack (371012 - not included)
  • with 12 Volt full discharge protection

Model
A 1200
Ref. no.372121
Stored Energy2.1 J
2.1 J
max. discharge energy1.4 J
1.4 J
min. discharge energy0.48 J
0.48 J
max. voltage10700 V
10700 V
Voltage in Open Circuit9000 V
9000 V
Voltage at 500 Ohms4400 V
4400 V
theoretical fence length as per VDE40 km
40 km
max. fence length without vegetation10 km
10 km
max. fence length with medium vegetation5 km
5 km
max. fence length with high vegetation1.5 km
1.5 km
Approx. Number of Electrifiable Nets5
5
Qty 1 m earth posts2
2
